Perfect for automotive and solar applications.
Features:
- Universal DC input 12.0V-30.0V?0.2V For Solar/12.0V-15.0V?0.2V For car
- Compatible with Lead Acid,Li-ion, Gel and AGM batteries
- Fitted with colour-coded 50A high-current (Anderson-compatible) connectors
- High efficiency and high reliability
- Battery type select function
- Protection :Short Circuit/Over-temperature/Reverse polarity
- E24/CE/RoHs approved
- IP65-rated enclosure - dust tight and watertight against light pressure water spray
Specifications:
Input voltage
- Solar charging: 12.0V-30.0V±0.2V
- Car generator charging : 12.0V-15.8V±0.2V
Output voltage
- GEL: 14.2V±0.2V
- CAL: 14.2V±0.2V
- STD: 14.4V±0.2V
- AGM: 14.8V±0.2V
- LiFePo4: 14.6V±0.2V
Output current : 20A±0.5A
Charging efficiency: Full load ≥90%;Maximum efficiency reaches 97%
Plugs to suit those supplied with the charger: Grey: PT4425 / Red: PT4426 / Yellow: PT4543
Working mode
- Solar charging (default priority)
- Car generator charging
- Five speed battery type adjustment
Product size : 205x105x51mm (230mm long including mounting flanges)
Product weight : 1.2KG
